3/4" Bent Nose Hose Bibb with Wall Flange
Model Number: 8120-LF Series
Hose Bibb shall be Murdock model 8120-LF. Model shall include a heavy brass body, furnished with a lockshield bonnet and removable loose key handle. Valves close with the wearing parts including the seat. Inlet is 3/4”-14 NPTI, outlet is 3/4”-11.5 NHE.
Vacuum breakers are atmospheric type and conform to the requirements of ASSE Standard 1011.
Hose valves meets the lead free requirements where the wetted surface of this product contacted by water contains less than .25% lead and are CUPC certified by IAPMO for U.S. and Canada. Check local authority for vacuum breaker requirements.
Vacuum breakers are atmospheric type and conform to the requirements of ASSE Standard 1011.
Hose valves meets the lead free requirements where the wetted surface of this product contacted by water contains less than .25% lead and are CUPC certified by IAPMO for U.S. and Canada. Check local authority for vacuum breaker requirements.
Product Function:
This valve is designed to be mounted on the wall. The spud from the wall is supplied by others. This valve features a wall flange.
Regularly Furnished:
This valve is designed to be mounted on the wall. The spud from the wall is supplied by others. This valve features a wall flange.
Regularly Furnished:
| Model Number | Finish |
|---|---|
| 8120-LF | Brass Valve only |
| 8120CP-LF | Polished Chrome Plated Brass Valve |
| 8120CR-LF | Rough Chrome Plated Brass Valve |
| 8121-LF | Brass Valve with Vacuum Breaker |
| 8121CP-LF | Polished Chrome Plated Brass Valve with Vacuum Breaker |
| 8121CR-LF | Rough Chrome Plated Brass Valve with Vacuum Breaker |
Product Details
- Mounting: Wall Mounted
- Material: Brass
- Inlet Size: 3/4"
- Activation: Spigot
- Finish Available: Rough Chrome Plated , Polished Chrome Plated
- Health/Environmental: Lead Free Fed. Law 111-380
|
