Misting Column
Model Number: M-PCMST84 Series
Column style mister shall be Murdock model MPCMST84, eight nozzle mister. Unit is to be pre-piped and hydrostatically tested.
Valve shall have internally mounted metering valve, pushbutton operated and requiring less than 5 pounds of force to activate. Timing shall be adjusted from 5 to 60 seconds.
Misting column nozzles shall be brass and fixture provides 0.18 gpm.
Unit shall be constructed of heavy duty 14 gage type 304 stainless steel polished to a satin finish with vandal resistant fasteners and shall include a 0.25 inch thick stainless steel bottom plate, providing secure mounting for shower.
Valve shall have internally mounted metering valve, pushbutton operated and requiring less than 5 pounds of force to activate. Timing shall be adjusted from 5 to 60 seconds.
Misting column nozzles shall be brass and fixture provides 0.18 gpm.
Unit shall be constructed of heavy duty 14 gage type 304 stainless steel polished to a satin finish with vandal resistant fasteners and shall include a 0.25 inch thick stainless steel bottom plate, providing secure mounting for shower.
Product Details
- Finish Available: All-Stainless Steel , Green , Red , Blue
- Material: Stainless Steel
- Mounting: Pedestal
